Specification

Main Input Voltage

230 V

Main Output Voltage

230 V

Rated power in W

480 W

rated power in VA

800 VA

Product or component type

Uninterruptible power supply (UPS)

Input Connection Type

NEMA 5-15P

output connection type

4 universal receptacle

Cable length

1.5 m

Number of cables

1

Battery type

Lead-acid battery

Provided equipment

User manual

Range of product

Easy UPS

Batteries & Runtime

ประสิทธิภาพ

View Efficiency Graph

Number of battery filled slots

0

Number of battery free slots

0

Battery recharge time

8 h

Battery life

3…5 year(s)

Extended runtime

0

General

Number of power module free slots

0

Number of power module filled slots

0

Redundant

No

UPS size

WS

Physical

Colour

Black

Height

9.2 cm

Width

16.1 cm

Depth

30.5 cm

Net weight

5.3 kg

Mounting preference

No preference

Mounting mode

Not rack-mountable

Two post mountable

0

USB compatible

No

Input

Network frequency

50/60 Hz +/- 5 Hz auto-sensing

Input voltage limits

170...280 V

Output

Maximum configurable power in W

480 W

Output frequency

50/60 Hz +/- 1 Hz unsynchronised

UPS type

Line interactive

Wave type

Stepped approximation to a sinewave

Graph display

1

Maximum configurable power in VA

800 VA

Transfer time

6 ms typical : 10 ms maximum

Conformance

Product certifications

CE
TISI

Standards

EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental

Ambient air temperature for operation

0…40 °C

Relative humidity

0…90 %

Operating altitude

0...6667 ft

Ambient air temperature for storage

-20…50 °C

Storage Relative Humidity

0…90 %

Storage altitude

0.0000000000…15240.0000000000 m

Acoustic level

40 dBA

IP degree of protection

IP20

Communications & Management

Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rate

156 J

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

23.7 cm

Package 1 Width

37.3 cm

Package 1 Length

14.3 cm

Package 1 Weight

5.6 kg

SCC14

10731304346859

Contractual warranty

Warranty

2 years repair or replace
