Specification

Main Input Voltage

230 V AC 1 phase

Main Output Voltage

230 V AC 1 phase

Rated power in W

650 W

rated power in VA

1200 VA

Product or component type

Uninterruptible power supply (UPS)

Input Connection Type

IEC 60320 C14

output connection type

4 universal
1 IEC 60320 C13

Cable length

1.2 m

Number of cables

1

Battery type

Lead-acid battery

Provided equipment

User manual

Range of product

Easy UPS

Batteries & Runtime

รันไทม์

View Runtime Graph

ประสิทธิภาพ

View Efficiency Graph

Number of battery filled slots

0

Number of battery free slots

0

Battery recharge time

8 h

Battery voltage

12 V

Battery capacity

9.0 Ah

Battery life

2…3 year(s)

Replacement battery

APCRBC175

Extended runtime

0

General

Max runtime

120 min

Number of power module free slots

0

Number of power module filled slots

0

Redundant

No

UPS size

WS

Physical

Colour

Black

Height

19 cm

Width

14 cm

Depth

39 cm

Net weight

7.5 kg

Mounting support

Floor

Mounting preference

No preference

Mounting mode

Not rack-mountable

Two post mountable

0

USB compatible

No

Input

Network frequency

50/60 Hz +/- 5 Hz auto-sensing

Input voltage limits

140...300 V 230 V AC

Cos phi

0.51

Output

Maximum configurable power in W

650 W

Output frequency

50/60 Hz +/- 1 Hz sync to mains

UPS type

Line interactive

Wave type

Stepped approximation to a sinewave

Full load runtime

00:01:00 650 W

Graph display

1

Half load runtime

00:05:00 300 W

Maximum configurable power in VA

1200 VA

Transfer time

6 ms typical : 10 ms maximum

Conformance

Product certifications

CE
CB

Standards

EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental

Ambient air temperature for operation

0…40 °C

Relative humidity

0…95 % non-condensing

Operating altitude

0...3000 m

Ambient air temperature for storage

-15…40 °C

Storage Relative Humidity

0…95 % non-condensing

Storage altitude

0…3000 m

Acoustic level

40 dBA

IP degree of protection

IP20

Surge Protection and Filtering

Surge energy rate

273 J

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

29.7 cm

Package 1 Width

49.5 cm

Package 1 Length

23.5 cm

Package 1 Weight

8.5 kg

SCC14

10731304404375

Contractual warranty

Warranty

2 years repair or replace
