Specification

Main Input Voltage

230 V AC 1 phase

Main Output Voltage

230 V AC 1 phase

Rated power in W

480 W

rated power in VA

900 VA

Product or component type

Uninterruptible power supply (UPS)

Input Connection Type

IEC 60320 C14

output connection type

2 universal
1 IEC 60320 C13

Cable length

1.2 m

Number of cables

1

Battery type

Lead-acid battery

Provided equipment

User manual

Range of product

Easy UPS

Batteries & Runtime

รันไทม์

View Runtime Graph

ประสิทธิภาพ

View Efficiency Graph

Number of battery filled slots

0

Number of battery free slots

0

Battery recharge time

8 h

Battery voltage

12 V

Battery capacity

9.0 Ah

Battery life

2…3 year(s)

Replacement battery

RBC17

Extended runtime

0

General

Max runtime

120 min

Number of power module free slots

0

Number of power module filled slots

0

Redundant

No

UPS size

WS

Physical

Colour

Black

Height

16 cm

Width

12 cm

Depth

35.5 cm

Net weight

6 kg

Mounting support

Floor

Mounting preference

No preference

Mounting mode

Not rack-mountable

Two post mountable

0

USB compatible

No

Input

Network frequency

50/60 Hz +/- 5 Hz auto-sensing

Input voltage limits

140...300 V 230 V AC

Cos phi

0.53

Output

Maximum configurable power in W

480 W

Output frequency

50/60 Hz +/- 1 Hz sync to mains

UPS type

Line interactive

Wave type

Stepped approximation to a sinewave

Full load runtime

00:01:00 480 W

Graph display

1

Half load runtime

00:06:30 240 W

Maximum configurable power in VA

900 VA

Transfer time

6 ms typical : 10 ms maximum

Conformance

Product certifications

CE

Standards

EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental

Ambient air temperature for operation

0…40 °C

Relative humidity

0…95 % non-condensing

Operating altitude

0...3000 m

Ambient air temperature for storage

-15…40 °C

Storage Relative Humidity

0…95 % non-condensing

Storage altitude

0…3000 m

Acoustic level

40 dBA

IP degree of protection

IP20

Surge Protection and Filtering

Surge energy rate

273 J

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

25 cm

Package 1 Width

43 cm

Package 1 Length

19.7 cm

Package 1 Weight

6.5 kg

SCC14

10731304404368

Contractual warranty

Warranty

2 years repair or replace
