Rating

VA
WATT

800VA
480W

Input

Voltage
Frequency

220 VAC +/-25%
50/60Hz. +/-10% (Auto Sensing)

Output

Voltage
Frequency
Wave Form


220 VAC +/-10%(AVR), +/-5%(Battery)
50Hz. +/-0.1%
 Sine Wave In Normal Condition
Modified Sine Wave In Backup Condition

System Protection

System Design
Transfer Time
Surge Energy Dissipation
Noise Filter
Overload & Short Circuit

Line Interactive UPS with Stabilizer, Microprocessor Control
Typical 2 ms.
320 Joules (6500A)
EMI Suppression
Reset Fuse Protection

Battery

Type
Recharge Time
Backup Time

Maintenance Free Sealed Lead-acid Battery
4-6 Hours (90% After Fully Discharged)
Backup Time 15-30 Min. (Depend on loads)

Indicator

LCD Display

AC Mode, Battery Mode, Input Voltage, Output voltage, Battery Level,
Charging Battery, Load Level, Low Battery, Overload, Fault & Battery Replace

Environment

Ambient Temperature
Audible Noise
Relative Humidity
Safety
Electromagnetic Compatibility


0 to +40 ºC
< 40db(1 Meter)
90% (Non-Condensing)
IEC/EN62040-1;IEC/EN60950-1

IEC/EN62040-2;IEC61000-4-2;IEC61000-4-3;IEC61000-4-4;IEC61000-4-5;

IEC61000-4-6;IEC61000-4-8

Software

USB Port

Window 2000, 2003, XP, Vista, 2008, 7, Linux, Unix, Max

Standard

Regular Approvals

TISI1291:2553, 2555, ISO9001:2015, ISO14001, CE, FCC, RoHS

Dimensions

WxDxH (mm.)

298x101X142

Weight

Kilogram

4.5 kg.
