12 Core Wall Mount Fiber Optic Enclosure – LC Single-Mode Complete Set

The 12 Core Wall Mount Fiber Optic Enclosure is designed as a compact, professional termination and splice solution for modern fiber networks.This enclosure comes as a complete ready-to-use set, including LC duplex adapters, LC pigtails, splice protection sleeves, and internal cable management. It significantly reduces installation time and eliminates the complexity of sourcing multiple fiber accessories separately. The fully metal, powder-coated steel construction ensures durability, stability, and long-term reliability in real-world installations.
With optimized internal layout, it supports clean fiber routing, safe splicing, and easy maintenance. The enclosure is suitable for both single-mode and multi-mode fiber applications. Dual doors with key lock provide enhanced security and controlled access. Ideal for wall-mounted installations where space efficiency and professional finish are required.

Order include:

- 12 Core Wall mount enclosure fiber optic: 1 pcs.

- LC/UPC Pigtail fiber optic Single-mode G.652.D, OD:0.9mm, 1M, 12 Color: 12 pcs

- 12 Core LC/UPC adapter plate duplex: 1 set

- Splice tray 12 Core: 1 pcs

- Ptotection sleeve 60mm: 12 pcs.

Functions / Features

- Wall-mount enclosure with maximum capacity 12 cores (Complete Set)

- Supplied complete with LC duplex adapters (Single-Mode)

- Includes LC pigtail OD 0.9 mm, 1 m length, 12-color coded

- Includes splice protection sleeves 60 cm for safe fiber joint protection

- Supports splice trays for 12–24 cores

- Two cable entry points for in & out fiber routing

- Heavy-duty powder-coated steel, fully metal construction

- Compatible with Single-Mode and Multi-Mode fibers

- Accommodates up to 2 snap-in adapter plates, supporting 6 / 12 ports (ST, SC, FC, LC)

- Easy cable holder design with ability to stack 2 splice trays, fixed securely by screws

- Dual doors with key locking system for enhanced security

- Compact dimension: W 335 × D 90 × H 235 mm

Applications

- FTTH / FTTB fiber termination points

- Building backbone and floor distribution fiber management

- CCTV and IP camera fiber connection points

- Industrial network and structured cabling systems

- Telecommunication rooms and control rooms

- Data communication and LAN fiber distribution

- Small to medium fiber aggregation points in commercial buildings
