OVERVIEW

The B1-H1016 is a high performance and easy-to-maintain high speed forwarding Ethernet switch independently developed by BISMON. It is suitable for hotels, banks, campuses, factory dormitories, and small and medium-sized enterprises.

The B1-H1016 has 16*10/100M adaptive RJ45 ports. Each port support full line-speed forwarding. 4M large-capacity cache to ensure timely transmission of large files and stable video streaming. 7*24 hours of stability, and no disconnection effectively solving problems such as video freezes and picture loss in high-definition surveillance environments. Plug and play, no configuration, simple and convenient to use.

FEATURE

10/100M access, full line-speed forwarding

- Support non-blocking wire-speed forwarding.

- Support full-duplex based on IEEE 802.3x and half-duplex based on Backpressure.

- Support 10/100M adaptive RJ45 port, plug and play, to meet the networking needs of various scenarios.

Stable and reliable

- CCC, CE, FCC, RoHS.

- Plug and play, no configuration, simple and convenient.

- The user-friendly panel can show the device status through the LED indicator of PWR and Link.

- Adopt high stability power supply, high redundancy design to provide long-term stable power output.

- Low power consumption, no fan, metal housing, and excellent heat dissipation to ensure the stable operation of the switch.

DIMENSION
