Specification

Interface

Fixed port                                                                                  24*1000 Base-T, 2*10Gigabit SFP

Management Port                                                                  Support console

Power interface                                                                       Phoenix terminal, dual power supply redundancy

LED Indicators                                                                          PWR Link/ACT LED

Cable type & Transmission distance

Twisted-pair                                                                              0-100m (CAT5e,CAT6)

Monomode optical fiber                                                      20/40/60/80/100KM

Multimode optical fibre                                                        550m

Network Topology

Ring topology                                                                            Support

Star topology                                                                             Support

Bus topology                                                                              Support

Tree Topology                                                                            Support

Hybrid topology                                                                        Support

Electrical Specifications

Input voltage                                                                             DC36-75V/AC 100-240V 50-60HZ

Total Power consumption                                                     <36W

Layer 2&3 Switching

Switching capacity                                                                 160G

Packet forwarding rate                                                         95.23Mpps

MAC address table                                                                16K

VLAN                                                                                    Support 4K

Buffer                                                                                        12M

Forwarding delay                                                                  <10us

MDX/MIDX                                                                             Support

Flow control                                                                           Support

Jumbo Frame                                                                         Support 10Kbytes

Spanning Tree                                                                    Support STP/RSTP/MSTP

 Ring Protocol                                                                     Support ERPS

 Link Aggregation                                                               Support 12 group

 Multicast                                                                            Support IGMP Snooping

 Port Mirroring, Storm Control, Interface Counters    Support

 QINQ, 802.1X, Radius/Mac Certification                      Support

 Port Isolation                                                                     Support

 RMON                                                                                 Support

 NTP client                                                                           Support

 DHCP client                                                                         Support

 DHCP snooping                                                                  Support

 Ping/tracert test                                                                Support

Convergence

ACL                                                                                         ACL 500, IP standard ACL, MAC expand ACL, IP expand ACL

QoS                                                                                        QoS re-marking, priority mapping, SP, WRR queue scheduling

   engress rate-limited, egress rate-limit, Policy-based QoS

Management

 CLI, Console, Telnet, WEB Management                          Support

 SNMP                                                                                     Support SNMPv1/v2c/v3

 User Management, System Log, Upgrade Firmware     Support

 Configuration File Download/Upload                               Support

Environment

Operating temperature                                                           -40?~+75?

Storage temperature                                                                -40?~+75?

Relative humidity                                                                       5%~95% (non-condensing?

Thermal methods                                                                       Fanless design, natural cooling

MTBF                                                                                            100,000 hours

Mechanical Dimensions

Product size                                                                                   440*245*44mm

Installation Method                                                                     Rack

Weight                                                                                             3.6KG

EMC&INGRESS PROTECTION

IP Level                                                                                            IP40

Surge protection of Power                                                           IEC 61000-4-5   Level 3 (4KV/2KV) (8/20us?

Surge protection of Ethernet port                                             IEC 61000-4-5   Level 3 (4KV/2KV) (10/700us?

RS                                                                                                           IEC 61000-4-3   Level 3 (10V/m?

EFI                                                                                                          IEC 61000-4-4   Level 3 (1V/2V?

CS                                                                                                           IEC 61000-4-6   Level 3 (10V/m?

PFMF                                                                                                     IEC 61000-4-8   Level4 (30A/m?

DIP                                                                                                         IEC 61000-4-11   Level3 (10V?

EMI                                                                                                   CLASS A

ESD                                                                                                        IEC 61000-4-2   Level 4 (8K/15K?

Free fall                                                                                             0.5m

Authentication

Authentication                                                                                   CCC/CE/FCC/RoHS

Accessories

Accessories                                                                                          Equipment, terminals, optional power adapter, instructions, product certification
