Overview

The B1-IMC2400GP-SFP product is a Self-Configured Hardened Ethernet switch which provides 4 port 10/100/1000Base-TX + 2x1000Base-FX SFP port. The 10/100/1000Base-TX ports supports PoE+ (Power Sourcing Equipment) and compliant with IEEE 802.3at.

Comply with IEEE 802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE 802.3x, and IEEE802.3at. The product will provide PoE power to any IEEE802.3at/af compliant network device. It supports IGMP snooping which significantly saves the network bandwidth and reduces network load. With its reliable design and ease of use, the product is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.

Features

• Automatically support IGMP (Multicasting)

• Supports 10/100/1000Mbps-Full/Half-duplex,

• Auto-negotiation, Auto MDI/MDI-X

• Supports external 1000BASE SFP

• Supports Daisy-Chain connection

• Supports IEEE 802.3at PoE+(30W per port)

• Supports Light Hardware IGMP V1, V2, V3

• Supports Broadcast Storm Control

• Supports Relay output for power failure

• 1M bits frame buffer memory

• Supports 9K Bytes Jumbo Frame

• Supports the transmission of extra-long VLAN packets

• Supports Quality of Service (QoS) and ensuring the transmission of VoIP packets;

• Supports Energy Efficient Ethernet IEEE802.3az

• Redundant Power Inputs

• Supports Wall-mount and DIN-Rail installation

• Environmentally hardened -40°C to 80°C

• (-40°F to 176°F) operating temperature
