4-RJ45 10/100/1000 PoE(IEEE802.3bt) and 2-RJ45 Uplink (PoE++ :Max 95W / Port)


Part number : B1-IPS33064P-bt

Brand : BISMON

Price : 7,800.00 Baht
(Dealer price can log-in/ Exclude Vat)

Delivery time : 20 Days

Minimum order quantity : 1 pcs

Warranty : 3 Year





OVERVIEW

The B1-IPS33064P-bt is a full gigabit unmanaged bt industrial PoE switch independently developed by BISMON. It has 6*10/100/1000M RJ45 ports Port 1-4 can support 71W PoE super high power output complies with IEEE802.3bt and backward compatible with the IEEE802.3af/at PoE standard. Single-port PoE power output is 95W. As a PoE power supply device, it can automatically detect and recognize the power-receiving equipment that meets the standard and supply power through the network cable. It provides stable and safe terminals for PTZ network domes, high-power wireless AP, high-power network multimedia speakers, and high-power POE lighting, etc. through a network cable to meet the network environment that needs high-density PoE power supply. It is suitable for intelligent transportation, rail transit, electric power, mining, metallurgy and green energy. Industrial scenes such as construction set up a cost-effective and stable communication network.



Unmanaged model, plug and play, no configuration, easy to use.



FEATURE

Gigabit full-line speed forwarding

 • Gigabit RJ45 ports and dual RJ45 ports combination, high-speed high-bandwidth connection, to meet the networking needs of various scenarios.

 • Support non-blocking wire-speed forwarding.

 • Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.



Smart PoE power supply function

 • 4*10/100/1000Base-T RJ45 ports can support bt PoE power supply, meeting the demand for super high power PoE power supply in various scenarios.

 • The maximum output power of single-port POE is 95W, and the backwards compatibility IEEE802.3af/at PoE power supply standard automatically identifies PoE devices for power supply without damaging non-PoE devices.

 • Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.



Stable and reliable

 • CCC,CE, FCC, RoHS.

 • Low power consumption, aluminum alloy casing, No fan.

 • The user-friendly panel, it can show the device status through the LED indicator of PWR, Link/Act, PoE.



SPECIFICATION

Model                                                               B1-IPS33064P-bt

Interface Characteristics

Fixed                                                                 Port 4*10/100/1000M bt PoE ports (Data /Power)

  2*10/100/1000M uplink RJ45 ports (Data)

  2 groud of V+, V- redundant DC power interface (5P Phoenix terminal)

Ethernet Port                                                  10/100/1000Base-TX auto-sensing,full/half duplex MDI/MDI-X self-adaption

Twisted Pair Transmission                            10BASE-T: Cat3,4,5 UTP(≤100 meter)

 100BASE-TX: Cat5 or later UTP(≤100 meter)

 1000BASE-T: Cat5e or later UTP(≤100 meter)

Chip Parameter

Network Protocol                                          IEEE802.3 10BASE-T, IEEE802.3i 10Base-T

 IEEE802.3u 100Base-TX, IEEE802.3u 1000Base-T

 IEEE802.3x

Forwarding Mode                                          Store and Forward (Full Wire Speed)

Switching Capacity                                        12Gbps (Non-blocking)

ForwardingRate@64byte                             8.93Mpps

MAC                                                                 2K

Buffer Memory                                              2M

Jumbo Frame                                                  9.2K

LED Indicator                                                   Power: PWR (green), network: Link (yellow), PoE: PoE (green)

PoE & Power

PoE Port                                                           Port 1 to 4 @bt POE and backward compatible with IEEE802.3af/at

Power Supply Pin                                           Defaul 1/2 (+), 3/6 (-), 4/5 (+), 7/8 (-)

Max Power Per Port                                      95W; IEEE802.3af/at/bt

Total PWR / Input Voltage                            240W / (DC48-57V)

Power Consumption                                     Standby<6W, Full Load<240W

Input Voltage / Interface                              48-57VDC, 5P industrial phoenix terminal, anti-reverse protection

Power Supply                                                 No, optional 48V/240W industrial power supply

Physical Parameter

Operation TEMP / Humidity                        -20~+75°C;5%~90% RH Non condensing

Storage TEMP / Humidity                            -40~+85°C;5%~95% RH Non condensing

Dimension (L*W*H)                                     119*100*30mm

Net /Gross Weight                                        <0.5kg /<1.2kg

Installation                                                     Desktop, 35mm DIN rail mounting

Certification & Warranty

Lightning protection / protection level

Lightning protection: 6KV 8/20us; Protection level: IP40

IEC61000-4-2(ESD):±8kV contact discharge,±15kV air discharge

IEC61000-4-3(RS):10V/m(80~1000MHz)

IEC61000-4-4(EFT): power cable:±4kV; data cable:±2kV

IEC61000-4-5(Surge):power cable:CM±4kV/DM±2kV; data cable:±4kV

IEC61000-4-6(radio frequency transmission):10V(150kHz~80MHz)

IEC61000-4-8(power frequency magnetic field):100A/m;1000A/m ,1s to 3s

IEC61000-4-9(pulsed magnet field):1000A/m

IEC61000-4-10(damped oscillation):30A/m  1MHz

IEC61000-4-12/18(shockwave):CM 2.5kV,DM 1kV

IEC61000-4-16(common-mode transmission):30V; 300V,1s

FCC Part 15/CISPR22(EN55022):Class A

IEC61000-6-2(Common Industrial Standard)

Mechanical Properties

IEC60068-2-6 (anti vibration)

IEC60068-2-27 (anti shock)

IEC60068-2-32 (free fall)

Certification                                                  CCC, CE mark, commercial, CE/LVD EN60950, FCC Part 15 Class B, RoHS

Warranty                                                       5 years, lifelong maintenance.
