Name: 48 Port Wall Outdoor Cabinet for CCTV or IP Camera(ตู้เปล่า)
Brand: BISMON
SKU: B1WM48CCOUT
Price: 9868.00 THB
Availability: InStock

48 Port Wall Outdoor Cabinet for CCTV or IP Camera(ตู้เปล่า)

Part number : B1-WM48CC-OUT

Brand : BISMON

Price : 9,868.00 Baht

(Dealer price can log-in/Ex-Vat 7%)

Credit Card:

(Online ชำระด้วยบัตรเครดิต ไม่มีชาร์จ)

OVERVIEW

Wall-Mount Outdoor Fiber Optic made of EG(Electro-Galvanized) steel high quality and a long time for use. They can compliant with the IP55 standard. they can accommodate the fiber from12-48 fiber. Cable entry 5 port use cable glands EG/PG29 depend on cable dia. The cable can be held the preformed holes by a 2 section cable inlet or cable feed-through grommet

Specification

Brand	Bismon
Model	B1-WM48CC-OUT
Equipment Type	Wall Mount Outdoor
Size	450 mm x 400 mm x 250 mm (HighxWidthxDepth)
Standard	Compliant IP55
Material	(EG)-Electro Galvanised Steel
Application	Can use for CCTV & IP Camera solution or other fiber optic solution
Features	• One door lockable and Double panel left & right airflow
	• Double folded gutter at door frame to increase rigidity and prevents water from entering while the door is opened.
	• Provided 4mm thickness CNC foam gasket for protection waterproof for body closure
	• 4 welded studs for fixing mounting plate and service equipment inside.
	• Surface finished cabinet with epoxy-polyester coating, grey color.
	• All screw or nut made of stainless steel
	• Can Change one panel 12-48 port Max. Capacity use for snap-in plate 6 or 12 port
	• Can support Adaptor fiber type to FC-D type, SC, ST, LC, Max:snap-plate 4 pcs
	• Can support splice tray 12 or 24 port maximum 6 ea
	• Can support FAN 4”x4” for airflow, installation Fan 3 point: Top/bottom/ 2 beside (Option)



Option (Made to order)	-
