OVERVIEW

RS485 splitter converts 1 channel RS485 data into 8 channels RS485 data isolated output. It offers signal splitter and signal driver under communication controlling. RS485 output signal safely isolated under communication is convenient to check .it could make RS485 port as input. Communication port with thunder proof and surge protection, short circuit production design. system status indicator RS 485 output can transmit signals. The devices are directly compatible with NTSC, PAL, and SECAM camera systems.

Data RS485 splitter is a high-performance multifunctional RS 485 interface splitter, it has external power, this features small size, far transmission distance, high speed and stability. It is widely used in security and surveillance system, attendance system and IC card charging system. RS485 sharer has multi-channel RS485 signal input, 1 channel RS485 output, Each port’s communication distance surpasses 1200 meters, It can extend the data communication range, improve the reliability of data transmission.

Features

•1 x RS485 Inputs; Only one Can be Active

• Inputs and Outputs are Isolated

• Can be Cascaded to other Serial splitters

• Each port’s communication distance surpasses 1200 meters (4,000 ft);

• solve the question when one control

• Connect up to 64 RS-485 cameras or devices.

• 2 pin flat blade attachment plug adapter included.

• RS485 port has anti-static and anti-thunder design;

• Various ports isolate mutually, the unwanted signal will not affect other channels, especially qualify star connection data communication way.

• NTSC, PAL or SECAM Video Compatible

• LED Indicators for Instant System Monitoring

• Produce according to customer's specifications, providing OEM

Typical Application

Data RS485 splitter is widely used in security and surveillance system, attendance system and IC card charging system, it is a data conversion product which has excellent cost performance. It can extend the data communication range, improve the reliability of data transmission.
