Input

Voltage Range 200V: 150-234V / 208V: 156-243V / 220V: 162-268V /

230V: 170-280V / 240V: 177-290V

Nominal Frequency 50/60 Hz (Auto-Detection)

Connection IEC C20

Phase Single phase with ground

Output

Voltage 200 / 208 / 220 / 230 / 240 Vac

Voltage Regulation ±1.5% (Batt. Mode)

Frequency Range 50 Hz or 60 Hz ± 1 Hz

(Batt. Mode)

Connection IEC C13 (4+4)

Overload 103% ~ 120%: 5 minutes (1 minute @ Battery mode),

120% ~ 150%: 10 seconds,

>150%: UPS shutdown immediately

Current Crest Ratio 3:1

Harmonic Distortion Linear load (full load) ≤2%, Non-linear load (full load) ≤5%

Waveform (Batt. Mode) Pure Sinewave

Battery Battery Type 12V/9Ah

Sealed lead-acid battery

Numbers 4

Recharge Time 4 hours recover to 90% capacity

Interface

Standard RS-232 Port x 1, USB Port x 1, MINI Slot x 1, Surge Protection, REPO

Efficiency

Normal Mode

AVR Mode 96.5%

Environment

Operating Temperature 0 ~ 40°C

Relative Humidity 20 ~ 90 % RH (non-condensing)

Noise Level < 45 dBA @ normal mode , < 55 dBA @ Battery mode

Physical Dimensions (W x D x H) 438 x 510 x 88 mm

Net Weight (kg) 21.3
