OVERVIEW
B1-IPS31064 product components were rigorous screened, have superior performance in stability, environmental adaptability. Shells were made by aluminum extrusion, more lighter, stronger, better resistance ability to corrosion and electromagnetic interference, ensure stability and security of Industrial Ethernet Switch, plus standard DIN-35 rail type installation method. Power input also chooses a suitable industry-standard types of power, to get more powerful suitability to environment.
4x 10/100M RJ45 ports, 2x 10/100M adaptive Ports, for connecting with devices like computer, switch, hub, server, etc, as well as powering network camera, VoIP, wireless AP and other devices. It simply connects remote multiple motherboard servers, relays, hubs, terminals and multiple terminals.
FEATURE
• 4x 10/100M RJ45 Ports, 2x 10/100M adaptive Ports
• Support IEEE802.3x flow control for Full-duplex Mode and back pressure for Half-duplex Mode
• Auto-Negotiation for Full-duplex Mode and Half-duplex Mode
• LED indicators
• Provides rail-type installation method
• Electromagnetic compatibility of up to 4 grade standards
• IP40 protection class
• Superior performance, successfully used in industrial field
SPECIFICATION
Model B1-IPS31064
Interface Characteristics
Fixed Port 6*10/100Base-TX RJ45 ports (Data)
2 set of V+, V- redundant DC power ports (5 Pin Phoenix terminal)
Twisted Pair Transmission 10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-T: Cat5e or later UTP(≤100 meter)
Ethernet Port 10/100Base-TX, auto-sensing, Full/half duplex MDI/MDI-X self-adaption
Chip Parameter
Network Protocol IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3u 100Base-FX, IEEE802.3x
Forwarding Mode Store and Forward (Full Wire Speed)
Switching Capacity 1.6Gbps
Forwarding Rate@64byte 0.89Mpps
MAC 1K
Buffer Memory 768K
Jumbo Frame 1536bytes
LED Indicator Power: PWR (green), network: Link (yellow), Rate: Speed (green)
Power
Working Voltage 12-48VDC; 5 Pin industrial Phoenix terminal, support anti-reverse protection.
Power Consumption Standby<4W, Full load<5W
Power Supply No, optional 24V/24W industrial power supply
Physical Parameter
Operation TEMP / Humidity -40~+75°C;5%~90% RH Non condensing
Storage TEMP / Humidity -40~+85°C;5%~95% RH Non condensing
Dimension (L*W*H) 119*100*30mm
Net /Gross Weight <0.5 kg / <0.7 kg
Installation Desktop, DIN rail
Certification & Warranty
Lightning protection / protection level
Lightning protection: 6KV 8/20us; Protection level: IP40
IEC61000-4-2(ESD):±8kV contact discharge,±15kV air discharge
IEC61000-4-3(RS):10V/m(80~1000MHz)
IEC61000-4-4(EFT): power cable:±4kV; data cable:±2kV
IEC61000-4-5(Surge):power cable:CM±4kV/DM±2kV; data cable:±4kV
IEC61000-4-6(radio frequency transmission):10V(150kHz~80MHz)
IEC61000-4-8(power frequency magnetic field):100A/m;1000A/m ,1s to 3s
IEC61000-4-9(pulsed magnet field):1000A/m
IEC61000-4-10(damped oscillation):30A/m 1MHz
IEC61000-4-12/18(shockwave):CM 2.5kV,DM 1kV
IEC61000-4-16(common-mode transmission):30V; 300V,1s
FCC Part 15/CISPR22(EN55022):Class A
IEC61000-6-2(Common Industrial Standard)
Mechanical Properties
IEC60068-2-6 (anti vibration), IEC60068-2-27 (anti shock)
IEC60068-2-32 (free fall)
Certification CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS
Warranty 3 years, lifelong maintenance.
