Model

B1-58052FM

Interface Characteristics

Fixed Port

1*Console RS232 port (115200,N,8,1)

4*1/10G uplink SFP+ fiber ports (Data)

48*10/100/1000Base-T RJ45 ports (Data)

Ethernet Port

Port 1-48 support 10/100/1000Base-T auto-sensing, full/ half duplex MDI/ MDI-X self-adaption

Twisted Pair Transmission

10BASE-T: Cat3,4,5 UTP (≤100 meters)

100BASE-TX: Cat5 or later UTP (≤100 meters)

1000BASE-T: Cat5e or later UTP (≤100 meters)

Optical Fiber Port

1/10G SFP+ optical fiber port, default no include optical module (optional single-mode/ multi-mode, single fiber/ dual fiber optical module. LC)

Optical Fiber Port Expansion

Turbo overclocking 2.5G optical module expansion and ring network

Optical Cable/ Distance

Multi-mode: 850nm/ 0-500m (1G), 0-300m(10G)

Single-mode: 1310nm/ 0-40km, 1550nm/ 0-120km

Chip Parameter

Network Management Type

L3

Network Protocol

IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-X, IEEE 802.3ae 10GBase-LR/SR, IEEE 802.3x

Forwarding Mode

Store and Forward(Full Wire Speed)

Switching Capacity

216Gbps (non-blocking)

Forwarding

Rate@64byte

131Mpps

CPU

Dual core 1GHz

DRAM

2GB

FLASH

256MB

MAC

32K

Buffer Memory

16MB

Jumbo Frame

12KB

LED Indicator

Power: PWR (Yellow), System: SYS(Yellow), Network: Link (Yellow), Fiber port: L/A (Green)

Reset Switch

Yes, press and hold the switch for 10 seconds and release it to restore the factory settings

Power Supply

Total PWR / Input Voltage

60W/(AC100-240V)

Power Consumption

Standby<35W, Full Load<55W

Power Supply

Built-in power supply, AC100-240V 50-60Hz, 1.0A

Physical Parameter

Operation TEMP / Humidity

-20~+55°C, 5%~90% RH Non condensing

Storage TEMP / Humidity

-40~+80°C, 5%~95% RH Non condensing

Dimension (L*W*H)

440*290*44.5mm

Net /Gross Weight

3.6kg/ 4.5kg

Installation

Desktop, 1U/19’’ cabinet

Certification & Warranty

Lightning Protection

Lightning protection: 4KV 8/20us, Protection level: IP30

Certification

CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS

Warranty

2 years, lifelong maintenance.

Network Management Feature

Interface

IEEE802.3x flow control (Full duplex)

Port exception protection mechanism

Jumbo frame configuration, max 12000byte

Port real-time flow management (Flow Interval)

Optical module DDMI real-time digital diagnosis

Broadcast storm suppression based on port rate

Port EEE Green Ethernet Energy-Saving configuration and status view

Limit the rate of packet traffic on incoming and outgoing ports, the mini granularity 16Kbps and max 1Gbps

L3 Routing

ARP protocol, max 1000 entries

IPV4/IPV6 VRRP, the max group is 255

Pingv6, Telnetv6, TFTPv6, DNSv6, ICMPv6

IPV4/IPV6 VLANIF interface supports up to 128

IPV4 Equal Cost Routing, NG protocol, max1000 entries

IPV4/IPV6 static route/default route supports up to 128 entries

L3 network management function, IPV4/IPV6 dual-stack management

IPV4 dynamic routing, RIPv1/v2, OSPFv2, BGP4+, 4000 routing entries

IPV6 dynamic routing OSPFv3, BGP+, RIPng, IPV6 management, 1000 routing entries

L3 routing and forwarding, support communication between different network segments and different VLAN

VLAN

Voice VLAN, QinQ configuration, IEEE802.1q

VLAN based on MAC, VLAN based on the protocol

4K VLAN based on port, Port configuration of Access, Trunk, Hybrid.

Port Aggregation

LACP dynamic aggregation, static aggregation

Max 26 aggregation groups and 8 ports per group.

Spanning Tree

STP BPDU Guard, BPDU filtering and BPDU forwarding

STP (IEEE802.1d), RSTP (IEEE802.1w), MSTP (IEEE802.1s)

ERPS Ring Network

ERPS ring network, Recovery time less than 20ms, ITU-T G.8032

Multicast

MLD Snooping, Multicast VLAN

User quick log out, MVR (Multicast VLAN Registration)

IGMP Snooping v1/v2/v3 and 1024 multicast groups at most

Mirroring

Bidirectional traffic mirroring for basic ports

Supports 1-to-multiple mirroring, supports up to 4 port sessions

QoS

Flow-based Rate Limiting, Flow-based redirection

Flow-based Packet Filtering, Priority Mark/ Remark

802.1p/DSCP priority mapping, 8*Output queues of each port

Diff-Serv QoS, Queue Scheduling Algorithm (SP, WRR, SP+WRR)

ACL

Port-based Issuing ACL, ACL based on port and VLAN

L2 to L4 packet filtering, matching the first 80-byte message. Provide ACL based on MAC, Destination MAC address, IP Source, Destination IP, IP Protocol Type, TCP/UDP Port, TCP/UDP Port Range, and VLAN, etc.

Security

Port broadcast message suppression

SSL ensures data transmission security

Port isolation, Host data backup mechanism

Limit the number of MAC addresses learned

Anti-DoS attack, ARP intrusion detection function

Quadruple binding function of IP+MAC+VLAN+port

IP source address protection, MAC address black hole

User hierarchical management and password protection

SSH 2.0 provides a secure encrypted channel for user login

AAA & RADIUS certification, ARP message rate limiting function

IEEE802.1X authentication/ centralized MAC address authentication

DHCP

DHCP Client, DHCP Snooping, DHCP Server

Management

System work log, Link Layer Discovery Protocol

NTP clock, Cable length detection, SNMP V1/V2/V3

Ping detection, Web network management (HTTPS)

ONV-NMS platform cluster management (LLDP+SNMP)

One click recovery, View CPU real-time utilization status

FTP, TFTP, Xmodem, SFTP file upload and download management

Console/ AUX Modem/ Telnet/ SSH2.0 CLI command line configuration

System

Web browser: Mozilla Firefox 2.5 or higher, Google Chrome V42 or higher, Cat5 and above Ethernet cable

TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, Mac OS X) installed on each computer in the network Cat5 and above Ethernet cable
