Provider Mode Ports

Fixed port

8*10/100/1000 Base-T

Power interface

Phoenix terminal, dual power redundancy

LED Indicators

PWR ,Link/ACT LED

Cable type&Transmission distance

Twisted-pair

0-100m( CAT5e,CAT6)

Network Topology

Ring topology

Not Supported

Star topology

Supported

Bus topology

Supported

Tree Topology

Supported

Electrical Specifications

input voltage

DC12-58V  PoE 48-58V

Total Power consumption

Total power<5W ; PoE full load<245W

PoE Support

PoE port

1-8

PoE Protocol

802.3af, 802.3at

Pin Assignment

1,2,3,6

Layer 2 Switching

Switching capacity

20G

Packet forwarding rate

14.88 Mpps

MAC address table

16K

Buffer

2M

Forwarding delay

<5us

MDI/MDIX

support

Jumbo Frame

Supports 10KBytes

Mechanical Dimensions

Product size

46X104X143mm

Installation Method

Card rail installation

Weight

0.55KG

Environment

Operating temperature

-40°C ~ +75°C

Storage temperature

-40°C~ +75°C

Relative humidity

10%~90% does not support non condensing

Thermal methods

Fanless design, natural heat dissipation

MTBF

100,000 hour

EMC&INGRESS PROTECTION

IP Level

IP40

Surge protection of Power

IEC 61000-4-5  Level 3 (4KV/2KV?? 8/20us)

Surge protection of Ethernet port

IEC 61000-4-5  Level 3 (4KV/2KV?? 10/700us)

ESD

IEC 61000-4-2  Level 4? 8K/15K?

Authentication

Authentication

Inspection reports and network access permits from the Ministry of Public Security and the Ministry of Industry and Information Technology CE/FCC/RoHS
