Card Media Convertor for Chassis 10/100/1000Base-TX to 1000Base-SX,MM 550M,SC,port


Part number : B1-3630-C

Brand : BISMON

Price : 3,852.00 Baht
(Dealer price can log-in/ Exclude Vat)



OVERVIEW

10/100/1000Base-TX to 1000Base-SX,MM 550M,SC,port Module Card Convertor 10/100Base-TX to 100Base-FX ,(MM,SC Port) The Media Converter complies with IEEE802.3,IEEE802.3u,IEEE802.3x Standards.It is designed to convert data signal between 10/100Base-TX and 100Base-FX Ethernet .The data signal converted by such high performance media converter can be transmitted up to 120Km maximum by fiber-optical cable.The Converter is equipped with two fiber optic connectors (One for transmitting-TX and another for receiving-RX),two RJ-45 Jack and one external power supply receptacle.Six LED indicators are built-in for easy diagnosing and monitoring the status of power, Unshielded Twisted Paired (UTP) Link ,UTP Activity,Fiber Link,Fiber Activity,Full duplex and data rates,It can configured automatically for Full Duplex or Half Duplex operation.It is compact,cost-effective,low dissipative,high reliable and stable,It can be used in standalone applications with 220VAC or 48VDC power supply optional.

Specification

Product Name 10/100/1000Base-TX to 1000Base-SX,MM 550M,SC,port
Model B1-3630-C
Ports 1x copper cable RJ45 port(Fast Ethernet TX) +1x fiber SC port(Fast Ethernet FX)
Bandwidth Fiber Bandwidth:155Mbps; Ethernet Bandwidth: 1.6Gbps (non-blocking)
MTBF 190,000 hours (about 21 years)
Forwarding Mode Store and forward
Network Protocol IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow Control; IEEE 802.1af DTE Power via MDI;
Optical Fiber Multi-mode dual fiber, SC fiber port(1000M-FX)
Optical Distance 550m
Wavelength 850,1300nm
LED Display System, Power, Connecting, working status
Power Consumption 2.5W
Dimensions (L x W x H) 11.6×8.5×2.5cm
Working Temperature -20°- 75°C
Certification UL, CE, FCC, RoHs
Warranty 2 year warranty
