OVERVIEW

The B1-POE33108P is a gigabit unmanaged PoE switch independently developed by ONV. It has 10*10/100/1000Base-T adaptive RJ45 ports. Port 1-8 can support IEEE 802.3 af/at PoE standard. Single-port PoE power reaches 30W, and the max PoE output power is 110W (at-250W). As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. It can supply power to POE terminal equipment such as wireless AP, IP camera, VoIP phone, building visual access control intercom, etc. through a network cable to meet the network environment that needs high-density PoE power supply. It is suitable for hotels, campuses, parks, shopping malls, scenic spots, hospitals, factory dormitory and small and medium-sized enterprise. Unmanaged model, plug and play, no configuration, easy to use.

FEATURE

Full gigabit access, full-line speed forwarding

- Support non-blocking wire-speed forwarding.

- Support full-duplex based on IEEE802.3x and half-duplex based on Backpressure.

- Support all-line high-speed forwarding,user-flexibly flexible networking, to meet the needs of various scenarios networking.

Intelligent PoE power supply

- Comply with IEEE 802.3 af/at PoE standard, automatically identify PoE devices for power supply, and not damage non-PoE devices.

- Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

- 8*10/100/1000Base-T RJ45 support PoE power, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

Stable and reliable

- CCC,CE, FCC, RoHS.

- Plug and play, no configuration, simple and convenient.

- The user-friendly panel can show the device status through the LED indicator of PWR, Link, PoE.

- Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.

- Low power consumption, with fan, galvanized steel shell, excellent heat dissipation to ensure stable operation of the switch.

DIMENSION
