OVERVIEW

MTP-Adaptor Front Panel, Standard

The USCONEC MTP is a MPO compatible connector that provides quick and reliable connection for up t 12 fibers. Available in single mode with a typical loss of 0.25dB and multimode with a loss of 0.20dB. Four and eight eight fiber MTP connectors are available

Application:

 • Telecommunications

 • Local area network

 • Fiber optic sensors

 • Testing instruments

 • CATV

Feature:

 • Compatible with NTT-FC, NTT-S C standard & S T connector

 • PC ferrule with20mm radius fast polishing

 • 8-degree angle PC ferrule Ceramic/Zirconia with ultra-low insertion loss

 • Low back reflection los s

 • Easy to handle

 • Environmentally stable

 • Typical Insertion Loss, dB: Single mode (9/125um) = 0.15

 • Typical Insertion Loss, dB: Multi mode(50,62.5/125um) = 0.3

 • Operating Temperature, C: - 40 ~ +75

 • Storage Temperature, C: - 55 ~ + 85
