Specification

Fixed port                                                        4*1000 Base-X, 8*10/100/1000Base-T

Power interface                                              Phoenix terminal, redundant dual power supply

LED Indicators                                                 PWR, OPT, NMC, ALM

Cable type & Transmission distance

Twisted-pair                                                     0-100m (CAT5e,CAT6)

Monomode optical fiber                                20/40/60/80/100KM

Multimode (optical) fiber                               550m

Network Topology

Ring topology                                                  Unsupported

Star topology                                                   Support

Bus topology                                                   Support

Tree Topology                                                 Support

Hybrid topology                                              Support

Electrical Specifications

Input voltage                                                   DC10-58V

Total Power consumption                              <6W

Layer 2 Switching

Switching capacity                                          40G

Packet forwarding rate                                   26.7Mpps

MAC address table                                         16K

VLAN                                                                  4K

Buffer                                                                8M

Forwarding delay                                            <10us

MDX/MIDX                                                       Support

Flow control                                                     Support

Jumbo Frame                                                   Support 10K Bytes

Environment

Operating temperature                                  -40C~+75C

                                                                            The device is testedfor 4 hours at temperatures in 85C

Storage temperature                                      -40C~+85C

Relative humidity                                            5%~95% non-condensing

Thermal methods                                            Fanless, natural cooling

MTBF                                                                 100,000 hours

Mechanical Dimensions

Product size                                                     143X104X48mm

Installation Method                                        DIN rail

Weight                                                              0.58KG around

EMC&INGRESS PROTECTION

IP Level                                                             IP50

Surge protection of Power                           IEC 61000-4-5   Level X(10KV/10KV)(8/20us)

Surge protection of Ethernet port              IEC 61000-4-5   Level X(6KV/4KV)(10/700us)

RS                                                                      IEC 61000-4-3   Level 3(10V/m)

EFI                                                                     IEC 61000-4-4   Level 3(1V/2V)

CS                                                                      IEC 61000-4-6   Level 3(10V/m)

PFMF                                                                IEC 61000-4-8   Level 4(30A/m)

DIP                                                                    IEC 61000-4-11   Level 3 (10V)

ESD                                                                   IEC 61000-4-2   Level 4(8K/15K)

Free fall                                                           0.5m

Authentication

Authentication                                                CCC, CE, FCC, RoHS

Accessories

Accessories                                                     Device, Terminals, Specification, Certificate, power adapter(optional)
