PoE Surge Protector


Part number : SP006P-K

Brand : BISMON

Price : 3,376.00 Baht
(Dealer price can log-in/ Exclude Vat)

download pdf



OVERVIEW



PoE (Power over Ethernet) Surge Protector

SP006P-K designed to protect Power-Over-Ethernet (PoE) data/communication lines in local and wide area networks up to 100 Base-T transmission speeds



SP006P-K: PoE Surge Protector

 • Performs a different function than grounding requirements.

 • Protects equipment from high voltage surges from nearby lightning strikes.

 • RJ45 Jack to RJ45 Jack

 • Power and signal line protection.

 • 10/100 Base • T CAT5/CAT5e compatible.

 • Support Mid • Span PoE and End Span PoE.

 • 802.3af PoE (Power over Ethernet) compatible.

 • Application for PoE (Power over Ethernet) protection



Application:

 • Computer Control Rooms

 • Educational Institutions

 • Server Farms

 • Commercial Offices

 • Manufacturing Facilities

 • Transmitter and Receiver Stations








Specification: SP006P-K

 • Surge Protection Attack Time: 1 ns

 • Maximum Surge Voltage: 4 KV

 • Surge Life: 300 surges of 100 Amps

 • Normal Resistance Across Coax: 10,000 M-ohm

 • Surge Resistance: Approx. 0 ohm

 • BAND PASS: 0~1 GHZ

 • Power Passing Capability: 130V DC / AC, 65 Vrms at 10 Amps

 • Insertion Loss: Less than 0.2 dB

 • Return Loss (75 ohms): 16dB

 • Connectors: RJ45

 • Dimension (mm): 85x25.4x25.4

 • Weight (g): 80
