Specifications

Rating

VA
WATT

1000VA
 550W

Input

Voltage
Frequency

220 VAC +/-25%
50/60Hz. +/-10% (Auto Sensing)

Output

Voltage
Frequency
Wave Form


220 VAC +/-10%(AVR), +/-5%(Battery)
50Hz. +/-0.1%
 Sine Wave In Normal Condition
Modified Sine Wave In Backup Condition

System Protection

System Design
Transfer Time
Surge Energy Dissipation
Noise Filter
Overload & Short Circuit

Line Interactive UPS with Stabilizer, Microprocessor Control
Typical 2 ms.
320 Joules (6500A)
EMI Suppression
Reset Fuse Protection

Battery

Type
Recharge Time
Backup Time

Maintenance Free Sealed Lead-acid Battery
4-6 Hours (90% After Fully Discharged)
Backup Time 15-30 Min. (Depend on loads)

Indicator

LCD Display

AC Mode, Battery Mode, AC Input Status, Output voltage, Battery Level,
High voltage, Normal voltage, Low voltage, Load Level, Low Battery, Overload

Special Features

Mute Alarm, Safety Power Button, Auto Start,
?Wide Angle and Eye protection LCD Display

Environment

Ambient Temperature
Audible Noise
Relative Humidity
Safety
Electromagnetic Compatibility


0 to +40 ºC
< 45db(1 Meter)
90% (Non-Condensing)
IEC/EN62040-1;IEC/EN60950-1

IEC/EN62040-2;IEC61000-4-2;IEC61000-4-3;IEC61000-4-4;IEC61000-4-5;

IEC61000-4-6;IEC61000-4-8

Software

USB Port

Window 2000, 2003, XP, Vista, 2008, 7, Linux, Unix, Max

Standard

Regular Approvals

TISI1291:2553, 2555, ISO9001:2015, ISO14001, CE, FCC, RoHS

Dimensions

WxDxH (mm.)

289x101x139

Weight

Kilogram

 4.9 kg
