Rating

VA
WATT

2000VA
1400W

Input

Voltage
Frequency

220 VAC +/-25%
50/60Hz. +/-10% (Auto Sensing)

Output

Voltage
Frequency
Wave Form

220 VAC +/-10%(AVR), +/-5%(Battery)
50Hz. +/-0.1%
Pure Sine Wave

System Protection

System Design
Transfer Time
Surge Energy Dissipation
Noise Filter
Overload & Short Circuit

Line Interactive UPS with Stabilizer, Microprocessor Control
Typical 2 ms.
320 Joules (6500A)
EMI Suppression
Reset Fuse Protection

Battery

Type
Battery
Recharge Time
Backup Time

Maintenance Free Sealed Lead-acid Battery
1-1.2kVA 12V 7.8X2 / 1.5kVA 12V 9.0X2  / 2kVA 12V 9.0X2
4-6 Hours (90% After Fully Discharged)
15-60 Min./ 5 Min at Full Load

Indicator

LCD Display

AC Mode, Battery Mode, Input Voltage, Output voltage, Battery Level,
Charging Battery, Load Level, Low Battery, Overload, Fault & Battery Replace

Environment

Ambient Temperature
Audible Noise
Relative Humidity
Safety
Electromagnetic Compatibility


0 to +40 ºC
< 45db(1 Meter)
90% (Non-Condensing)
IEC/EN62040-1;IEC/EN60950-1

IEC/EN62040-2;IEC61000-4-2;IEC61000-4-3;IEC61000-4-4;IEC61000-4-5;

IEC61000-4-6;IEC61000-4-8

Software

USB Port

Window 2000, 2003, XP, Vista, 2008, 7, Linux, Unix, Max

Standard

Regular Approvals

TISI1291:2553, 2555, ISO9001:2015, ISO14001, CE, FCC, RoHS

Dimensions

WxDxH (mm.)

380x158x198

Weight

Kilogram

11.5 kg.
